2015 Yamaha Raider Horsepower
Yamaha Star Raider Bullet Cow
Make Model | Yamaha Star Raider Bullet Cow |
Year | 2015 |
Engine | Four stroke, 48� V-Twin cylinder, SOHC, 4 valves per cylinder. |
Capacity | 1854 cc / 113 cu-in |
Bore x Stroke | 100 x 118 mm |
Cooling System | Air cooled |
Compression Ratio | 9.5;1 |
Induction | Twin-bore fuel injection (FI) |
Ignition | Electronic control unit (ECU) |
Starting | Electric |
Max Power | 73,6 kW 100 hp @ 4.250 rpm |
Max Torque | 167,8 Nm 17,1 kgf-m @ 2.500 rpm |
Transmission | 5 Speed |
Final Drive | Belt |
Front Suspension | 46 mm Telescopic fork |
Front Wheel Travel | 320 mm / 5.1 in |
Rear Suspension | Adjustable link Monocross |
Rear Wheel Travel | 88.9 mm / 3.5 in |
Front Brakes | 2x 298 mm discs |
Rear Brakes | Single 310 mm disc |
Front Tyre | 120/70-21 |
Rear Tyre | 210/40R18 |
Dimensions | Length 2570mm / 101.2 in Width 925 mm / 36.4 in |
Wheelbase | 1800 mm / 70.9 in |
Seat Height | 695 mm / 27.4 in |
Ground Clearance | 145 mm / 5.7 in |
Wet Weight | 333 kg / 734 lbs |
Fuel Capacity | 15.8 Liters / 4.2 gal |
The world�s ultimate midsize chopper-inspired custom, now with a new bold aerodynamic bullet cowl with a hint of outlaw that provides full coverage to eliminate wind fatigue...
The New Raider Bullet Cowl offers everything that makes the 2015 Yamaha Raider the world's premier chopper-inspired performance cruiser, and ups the ante. With a new aerodynamic cowl and a hint of outlaw styling providing full coverage to eliminate wind fatigue with allowing unobstructed views of the road. And with 113 cubic inches of air cooled, fuel injected V-Twin power below, there's virtually no limit to where the road can take you.
Features
Top Features:
NEW FOR 2015! Raider Bullet-Cowl offers a tougher look and excellent wind protection.
�The Raider was inspired by the custom chopper movement, but since it�s a Star, it had to also handle, stop and go.
�A 6-degree yoke angle�the first ever on a Star Motorcycle�makes it possible to achieve that custom raked-out look as well as neutral handling and straight-line cruisability: 33-degree rake plus 6 degrees yoke angle gives total rake of 39 degrees and 102mm of trail.
�Custom 5-spoke wheels carry a 120/70-21-inch bias tire up front, and a wide, 210/40-18 radial out back�the tallest and widest ever on a Star.
�Estimated 42 mpg* means this cruiser can go the distance between fill-ups.
Engine:
�113-cubic-inch (1854cc) air-cooled, OHV with 4 valves per cylinder, pushrod 48-degree V-twin pumps out max torque at just 2500 rpm and max power at 4500 rpm for powerful, relaxed cruising.
�Four pushrod-activated valves and two spark plugs per cylinder provide optimum combustion efficiency along with classically beautiful engine architecture.
�Ceramic-composite plated cylinders for superior heat dissipation with forged pistons cooled by oil jets. Provides outstanding reliability and longer engine life.
�9.5:1 compression ratio and aggressive cam timing increase power output across the board.
�Computer-controlled, twin-bore fuel injection monitors multiple engine parameters to calculate perfect mixture under all conditions; wide-angle 12-hole fuel injectors provide excellent atomization.
�A 3.5-liter airbox is hidden in the area below the fuel tank for great performance and clean styling.
�Two-into-one-into-two exhaust with Exhaust Ultimate Power valve (EXUP�) inside boosts torque in the 2500-3500-rpm range.
�Special custom-machining of the cooling fin edges gives a jewel-like appearance to the engine as light hits it from different angles.
SUSPENSION:
�All-aluminum cast frame is light, rigid and tuned for light, athletic handling. A light, Controlled-Fill, aluminum swingarm casting complements the bike�s lithe style.
�Low, sculpted seat holds the rider in place, and pullback bars reach back to enforce a casual, urban cruising style.
�A 6-degree yoke angle�the first ever on a street-legal Star Motorcycle�makes it possible to achieve that custom look as well as neutral handling and straight-line cruisability: 33-degree rake plus 6 degrees yoke angle gives total rake of 39 degrees and 102mm of trail.
�Custom 5-spoke wheels carry a 120/70-21-inch bias tire up front, and a wide, 210/40-18 radial out back�the tallest and widest ever on a Star.
�46mm fork tubes serve a sweet appearance and an excellent ride through 5.1 inches of wheel travel.
�A tucked-out-of-sight single shock out back provides a smooth ride under varying loads.
�Flangeless fuel tank carries a full 4.2 gallons of fuel.
�Front brake master cylinder with integrated lever operates a pair of 298mm front discs squeezed by strong monoblock calipers for excellent power and feel, with a 310mm disc out back.
�Strong, light and narrow belt final drive contains embedded carbon fiber for even greater strength.
�Wiring harness uses super-slim wires for compactness and lighter weight, and switchgear wiring is routed inside the handlebar for a clean appearance.
Additional Features:
�Left-thumb operated high-beam switch, and right-thumb activated accessory driving light switch for great visibility.
�Jewel-like fit and finish, and Star quality paint, chrome and attention to detail are evident all over the Raider.
�Cool, tank-mounted instrumentation complements the custom look, and contains analog speedometer and fuel gauge, along with twin digital tripmeters, odometer and self-diagnostics.
�Bright multi-reflector headlight, LED taillight, and custom amber LED turn signals behind clear lenses give a custom look.
�02 sensor and three-way catalyst reduce emissions.
Source: https://www.motorcyclespecs.co.za/model/yamaha/yamaha_Star%20Raider%20Bullet%20Cow%2015.htm
